English
Description
Product Specifications
GAUGE | |
Size | 15/17/19 |
Inner Wide Open Gear | Quick Release 135/Cylinder Shaft148 |
Five Way | Threaded Type Bb73//Pressed Type Bb92 |
The Tube | 30.9 |
Type | 15-inch/17-inch Clip-on Type |19-inch Type E |
Head Tube Bowl Set Size | 42/52 |
Wheel Set Maximum Loading | 29*2.3 |
Weight | About 1000g |
Product Parameters
SIZE | CF | L | A | B | F | P | T | D | R | G | REACH | STACK |
S/15 | 381 | 590 | 71.5 | 69.8 | 660 | 435 | 86 | 60 | 45 | 501 | 412 | 595 |
M/17 | 432 | 601 | 71.5 | 69.8 | 671 | 435 | 86 | 60 | 45 | 501 | 423 | 595 |
L/19 | 483 | 610 | 71.5 | 69.8 | 680 | 435 | 96 | 60 | 45 | 501 | 429 | 605 |
