Description
Product Specifications
GAUGE | |
Dimensions | 490/520/550 |
Five Way | Press Type Bb86.5 |
Front Dial Type | Direct Mounted |
Brake | Disc Brake |
Head Tube Bowl Set Size | 52/52 |
Maximun Capacity Of Wheel Set | 700*32 |
Weight | About 850g |
Product Parameters
SIZE | A | B | C | D | E | F | G | H | I | J | K | L | M |
490 | 456 | 531 | 120 | 410 | 577 | 74° | 72.5° | 74 | 375 | 47 | 975 | 514 | 372 |
520 | 473 | 541 | 137 | 410 | 583 | 74° | 74° | 72 | 375 | 47 | 982 | 549 | 384 |
550 | 494 | 563 | 157 | 410 | 595 | 73.5° | 73.5° | 73.5° | 375 | 47 | 994 | 570 | 394 |
